ASUS
ASUS ROG Equalizer
In stock (6 left) - ready to ship
Estimated delivery Monday 28 SeptemberDispatched within 24 hours by DPD
£44.99
- £44.99 ex VAT
Balanced Power Delivery
ROG Equalizer ensures balanced current delivery from PSU to ROG Equalizer, lowering graphics card connector temperatures and maintaining stable thermal performance below the 105°C material limit.
Under an extreme test scenario, we removed the middle 4 wires from the +12V cable to simulate potential current imbalance conditions that may occur with a standard 12V-2x6 PCIe cable. Even under these conditions, the ROG Equalizer maintained a temperature of approximately 73.4°C. In contrast, a standard 12V-2x6 PCIe cable reached around 146°C—far exceeding safe operating limits.
Specifications
| Cable length | 0.75 m |
| Connector 1 | PCI-E (16-pin) |
| Connector 2 | PCI-E x16 (Gen 4.0) |
| Connector 1 gender | Male |
| Connector 2 gender | Male |
| Product colour | Black |
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| Connector contacts plating | Gold |
| Purpose | Power supply unit (PSU) |
| Package width | 254 mm |
| Package depth | 56 mm |
| Package height | 36 mm |
| Package weight | 260 g |
| Quantity per pack | 1 pc(s) |
| Package type | Box |
| Weight | 200 g |
Specifications provided by the manufacturer via Icecat.
