TP-Link N300 Wireless N Access Point
£30.99
- £30.99 ex VAT
What This Product Does
The TP-LINK Wireless N Access Point TL-WA801N is designed to establish or expand a scalable high-speed wireless N network or to connect multiple Ethernet-enabled devices such as game consoles, digital media adapters, printers, or network-attached storage devices to a wireless network. The AP supports a host of different functions that makes your wireless networking experience more flexible than ever before. Now, you can enjoy a better Internet experience when downloading, gaming, video streaming or any other applications that you may wish to use.
Wireless N - Speed & Range
Adopting IEEE 802.11n advanced MIMO (Multi Input Multi Output) technology, it simultaneously works through two antennas to Tx and Rx to overcome the interference and signal degradation when traveling long distances or through physical barriers in a small office or a large apartment, resulting in an incredible improvement in the wireless performance, even in a steel-and-concrete building. Above all, you could easily pick up the wireless network during long-distance connection where legacy 11g products may not!
Multiple Operating Modes
- Easy to Build WLAN
Supports multiple operation modes (Access Point, Multi-SSID, Client, Range Extender) to enable various wireless applications to give users a more dynamic and comprehensive experience when using their APs. Multiple operating modes also help you easily build wireless network for hard-to-wire locations or eliminating wireless dead zone.
Passive PoE Supported
- More Flexible Deployment
The TL-WA801N is able to be powered using an Ethernet cable to simultaneously send data and electricity to wherever your AP may be located even up to 100 feet away. This feature multiplies your options allowing you to place the AP in a position that is most convenient to get the best signal possible, such as on the wall or on the ceiling of your office.
- 300 Mbps wireless speed ideal for smooth HD video, voice streaming, and online gaming
- Supports multiple operation modes: Access Point, Multi-SSID, Client, and Range Extender modes
- Protects your home network with WPA2 encryption and makes quick connection with the push of a button
- Up to 30 meters (100 feet) of flexible deployment with included Passive Power over Ethernet Injector
Specifications
| Antenna direction type | Omni-directional |
| Certification | CE, FCC, RoHS |
| Antenna type | External |
| Antennas quantity | 2 |
| Reset button | Yes |
| Placement | Table |
| Product colour | White |
| WPS push button | Yes |
| Quality of Service (QoS) support | Yes |
| 2.4 GHz | Yes |
| 5 GHz | No |
| 6 GHz | No |
| Maximum data transfer rate (2.4 GHz) | 300 Mbit/s |
| Transmitting power (CE) | 15 dBm |
| Transmitting power (FCC) | 20 dBm |
| Automatic channel scanning | Yes |
| Receiver sensitivity | 11g 6Mbps: -90dBm\n11g 54Mbps: -77dBm\n11n HT20 MC7: -73dBm\n11n HT40 MC7: -70dBm |
| Frequency band | 2.4-2.4835 GHz |
| Harmonized System (HS) code | 85176990 |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Security algorithms | WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
| VLAN support | Yes |
| Power over Ethernet (PoE) type supported | Passive PoE |
| Automatic channel selection | Yes |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| AC adapter included | Yes |
| Quick start guide | Yes |
| Cables included | LAN (RJ-45) |
| PoE adapter included | Yes |
| Package width | 310 mm |
| Package depth | 223 mm |
| Package height | 70 mm |
| Package weight | 560 g |
| Quantity per pack | 1 pc(s) |
| Package type | Box |
| Firmware upgradeable | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Maximum data transfer rate | 300 Mbit/s |
| WAN connection | Ethernet (RJ-45) |
| Output voltage | 9 V |
| Output current | 0.6 A |
| DC-in jack | Yes |
| Power over Ethernet (PoE) | Yes |
| Width | 181.6 mm |
| Depth | 129.7 mm |
| Height | 34.7 mm |
| Networking standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u |
Specifications provided by the manufacturer via Icecat.
