StarTech.com 4-PORT HDMI KVM Switch
£341.99
- £341.99 ex VAT
Control four HDMI computers using a single console, with a built-in USB 3.0 hub for sharing additional peripheral devices
This 4-Port USB 3.0 HDMI® KVM switch lets you control four HDMI computers with a single monitor, keyboard and mouse. The KVM also features 3.5 mm audio and a built-in 3-port USB 3.0 hub.
Convenient and cost-effective USB 3.0 peripheral sharing
This KVM switch offers a built-in 3-port USB 3.0 hub that's separate from your HID keyboard and mouse, so you can share USB peripheral devices between each connected computer and avoid the expense of separate equipment. The USB 3.0 hub automatically switches your connected USB devices to the selected computer, saving you the hassle of disconnecting and reconnecting peripherals.
With support for USB 3.0, you can achieve data transfer rates up to 5Gbps, to ensure flawless performance for your USB peripherals - great for quickly transferring data to external USB 3.0 drives.
HD picture quality
Offering support for high-definition 1080p resolutions, this 4-port HDMI KVM switch has the ability to drive HDMI displays with crystal clarity, making it ideal for graphical applications that require 1920 x 1080 video resolutions.
Complete multimedia control
The KVM switch features auxiliary 3.5 mm audio ports that enable you to share independent analog audio, from each of your connected computers, with your desktop speaker set. Independent audio, along with 1080p HDMI video, gives you full multimedia control between different computers, making this KVM perfect for creative professional applications such as video and sound design or editing.
The SV431HDU3A2 is TAA compliant and backed by a StarTech.com 2-year warranty with free lifetime technical support.
Rackmount your KVM switch
If you’d like to mount this KVM switch to your server rack, StarTech.com offers a 1U Rackmount Bracket (sold separately) that turns this KVM into a rackmountable KVM.
- Easily share peripheral devices with built-in USB 3.0 hub
- High definition video quality with support for resolutions up to 1080p
- Full multimedia control with separate 3.5 mm auxiliary support
- No software or drivers required
- Independent HID keyboard and mouse ports
Specifications
| Compliance certificates | RoHS |
| Certification | CE, FCC, UL, PSE |
| Built-in display | No |
| LED indicators | Link, Power |
| Daisy chain | No |
| Rack mounting | Yes |
| Maximum cable length | 10000 m |
| On Screen Display (OSD) | No |
| Product colour | Black |
| Mean time between failures (MTBF) | 142000 h |
| Power plug type | Type M |
| Hot keys | Yes |
| Harmonized System (HS) code | 85176200 |
| Products per master (outer) case | 6 pc(s) |
| Master (outer) case width | 512 mm |
| Master (outer) case length | 323 mm |
| Master (outer) case height | 300 mm |
| Ethernet LAN | No |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -10 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Input current | 0.6 A |
| Input voltage | 100-240 V |
| Quick installation guide | Yes |
| Rubber feet | Yes |
| Package width | 299 mm |
| Package depth | 248 mm |
| Package height | 89 mm |
| Package weight | 1.6 kg |
| Plug and Play | Yes |
| Audio channels | 2.0 |
| Headphone outputs | 4 |
| USB connector type | USB Type-A |
| Number of computers controlled | 4 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | HDMI |
| Audio connections | Yes |
| Console ports | 3.5mm headphone, HDMI, USB A |
| Console USB ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity | 3 |
| Output voltage | 12 V |
| Output current | 1.5 A |
| DC-in jack | Yes |
| Compatible power plug types | AU, EU, UK, US |
| Maximum resolution | 1920 x 1080 pixels |
| Width | 130 mm |
| Depth | 220 mm |
| Height | 43 mm |
| Weight | 1.1 kg |
| IP control | No |
| Audio support | Yes |
Specifications provided by the manufacturer via Icecat.
